Cabling
16.1 List of used cables
I The numbers in the cable list correspond to those shown in the cabling
plans.
No. Name Number Routing
Basic
C1 CBL_FRONTPANEL T26139-Y4015-V301
Front panel module to system
board
C2 CBL_USB_30_650 T26139-Y3999-V505
USB 3.0 backup drive to
USB 3.0 front
C3 CBL_SATA_780 T26139-Y4028-V303 ODD to system board
C4 CBL_INTRUSION_SW T26139-Y3922-V121
Server side and front to
system board
C5 CBL_PWR_2x4P T26139-Y3959-V305
Power backplane to 2.5" HDD
backplanes / HDD ext. box /
PCIe SSD ext. box
C6 CBL_PWR_6P_6P T26139-Y3959-V306
Power backplane to 3.5" HDD
backplanes / HDD ext. box
C8 CBL_PWR_4P_2x4P T26139-Y3959-V307
Power backplane to HDD
backplanes / HDD ext. box
C9 CBL SAS MINI HD_620 T26139-Y4040-V1
Power backplane to SATA on
system board
C10 CBL HOST-BP 620 T26139-Y4040-V10
SAS backplane to HDD
extension box or system board
C11 CBL_SAS3.0_ 320 T26139-Y4040-V7
SAS backplane to
SAS 3.0 expander board
Accessible drives
C20 CBL_USB30_Dev T26139-Y4039-A80
USB 3.0 backup drive to
USB 3.0 INT
C21 CBL_SAS_Dev_PwSig T26139-Y4044-V2
SAS Backup drive to system
board SAS 3.0 slot 2/3
C23 CBL_SATA_Slim_Pow_400 T26139-Y3986-V302
slimline ODD to CBL PWR
(C8)
C24 CBL_PATA_Dev_Pow_410 T26139-Y4029-V1
Backup drive to CBL PWR
(C8)
C25 CBL_SATA_FULL_Pow T26139-Y3930-V601 ODD to CBL PWR (C8)
Table 6: List of used cables
