TX2560 M2 / RX2560 M2 Upgrade and Maintenance Manual
511
C26 CBL_SAS_Exp_Pow T26139-Y3959-V354
SAS expander board to SAS
backplane
C27 CBL_HOST_BPL_800 T26139-Y4040-V46 PCIe SSD bpl to PCIe Switch
Other options
C30 CBL_Front_VGA T26139-Y3994-V301 Server front to system board
C31 CBL_COM_300 T26139-Y3589-V651
Case rear side to system
board connector COM 1
C32 CBL_TPM_FBU02 T26139-Y4031-V102 FBU to TFM
C35 CBL_HDD_non_hplg T26139-Y4040-V29
SAS 3.0 expander to 2x 2.5"
non-hot-plug HDDs/SSDs
C36 CBL_OOB_4BPL T26139-Y4015-V607 System board to backplanes
C37 CBL_OOB_6BPL T26139-Y4015-V606 System board to backplanes
C40 CBL_LVP_700 T26139-Y3718-V301 LSD to system board
C41 CBL_ODD_Pwr T26139-Y3986-V305
slimline ODD to CBL PWR
(C8) - multibay box
No. Name Number Routing
Table 6: List of used cables
