304
Upgrade and Maintenance Manual TX2560 M2 / RX2560 M2
Expansion cards and backup units
9.3.3 Replacing expansion cards in standard slots
Note on network settings recovery
I
When replacing network controllers or the system board, network
configuration settings in the operating system will be lost and replaced
by default values. This applies to all static IP address and LAN teaming
configurations.
Ensure to note down your current network settings before replacing a
controller or the system board.
9.3.3.1 Preliminary steps
Ê
If applicable, "Note on network settings recovery" on page 304
Ê
"Suspending BitLocker functionality" on page 111
Ê
"Disabling SVOM boot watchdog functionality" on page 112
Ê
"Locating the defective server" on page 55
Ê
"Shutting down the server" on page 58
Ê
"Disconnecting the power cord" on page 59
Ê
Remove all external cables from the expansion card to be replaced.
Ê
"Getting access to the component" on page 61
Ê
"Locating the defective component" on page 57
9.3.3.2 Removing a defective expansion card
Ê
Remove the expansion card as described in section "Removing expansion
cards from standard slots" on page 300.
Ê
If the slot bracket on the defective expansion card is to be reused:
"Removing a slot bracket" on page 294
Upgrade and Repair Unit
(URU)
Hardware: 10 minutes
Tools:
Phillips PH2 / (+) No. 2 screw driver
