78
Upgrade and Maintenance Manual TX2560 M2 / RX2560 M2
Basic hardware procedures
4.5.1.4 Mounting the server in the rack
V CAUTION!
At least two people are needed to position the server on the rack rails.
(For the Japanese market, please refer to "
安全上のご注意
".)
Additionally, a lifter is required in the following cases:
– The server weighs more than 50 kg.
– The server weighs more than 21 kg and is to be installed above the
height of 25 U.
When using a lifter, this installation procedure needs to be carried out by
maintenance personnel.
I
Refer to the rack cabinet manuals for more detailed information on other
support systems.
Ê
If required, install the rack mounting bracket and rack system into the rack
as described in the "Rack Mounting Kit - RMK-F2 Drop-In" Mounting
Instructions.
I
The printed poster is contained in the rack mounting kit.
For configurations below 32 kg:
At least two people are needed to lift the server
into the rack cabinet.
For configurations below 55 kg:
At least three people are needed to lift the server
into the rack cabinet.
For configurations above 55 kg:
At least four people are needed to lift the server
into the rack cabinet.
