Fujitsu PRIMERGY TX2560 M2

334 Upgrade and Maintenance Manual TX2560 M2 / RX2560 M2
Expansion cards and backup units
Figure 240: MAC labels for D3255
9.5.1.3 PLAN EM 2x 10 GB SFP
Figure 241: DynamicLoM module D3265
P2:xxxx xxxx xxx2(6,A,E)
P3:xxxx xxxx xxx3(7,B,F)
P0:xxxx xxxx xxx0(4,8,C)
P1:xxxx xxxx xxx1(5,9,D)
P3
P1
P2
P0
