TX2560 M2 / RX2560 M2 Upgrade and Maintenance Manual
347
Expansion cards and backup units
9.6.2 Removing the serial interface
9.6.2.1 Preliminary steps
Ê
"Disabling SVOM boot watchdog functionality" on page 112
Ê
"Shutting down the server" on page 58
Ê
"Disconnecting the power cord" on page 59
Ê
"Getting access to the component" on page 61
9.6.2.2 Removing the serial interface
Ê
Remove the two bolts (see figure 253) and take out the serial interface.
I
The rectangular break-out remains open.
Ê
Disconnect the serial interface cable from the system board connector
"COM 1" (see figure 254).
9.6.2.3 Concluding steps
Ê
"Reassembling" on page 74
Ê
"Connecting the power cord" on page 87
Ê
"Switching on the server" on page 90
Ê
"Enabling SVOM boot watchdog functionality" on page 130
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
Tools:
nut driver 5 mm
