TX2560 M2 / RX2560 M2 Upgrade and Maintenance Manual
93
Basic hardware procedures
4.9 Handling the system fan holder
4.9.1 Removing the system fan holder
Figure 43: Removing the system fan holder
Ê
Press in on the two locking tabs (1) while slightly lifting up the system fan
holder.
Ê
Remove the system fan holder from the chassis (2).
