Fujitsu PRIMERGY TX2560 M2

332 Upgrade and Maintenance Manual TX2560 M2 / RX2560 M2
Expansion cards and backup units
9.5 DynamicLoM modules
9.5.1 Basic information
I When replacing network controllers, network configuration settings in the
operating system will be lost and replaced by default values. This applies
to all static IP address and LAN teaming configurations.
9.5.1.1 PLAN EM 2x 1GB T
Figure 237: DynamicLoM module D3245
DynamicLoM
module
Part number Bolt
length
Part number Screw M3 x 3.5 mm
for fixation
1Gb x2port S26361-D3245-A100 5 mm C26192-Y1-C65 C26192-Y10-C102
1Gb x4port S26361-D3255-A100 5 mm C26192-Y1-C65 C26192-Y10-C102
10Gb x2port
(SFP)
S26361-D3265-A100 8 mm C26192-Y1-C66 C26192-Y10-C102
10Gb x2port S26361-D3275-A100 /
S26361-D3285-A100
8 mm C26192-Y1-C66 C26192-Y10-C102
