TX2560 M2 / RX2560 M2 Upgrade and Maintenance Manual
459
System board and components
Ê
"Connecting the power cord" on page 87
Ê
"Switching on the server" on page 90
Ê
"Resuming BitLocker functionality" on page 136
14.3.3 Replacing the UFM
14.3.3.1 Preliminary steps
Ê
"Locating the defective server" on page 55
Ê
"Suspending BitLocker functionality" on page 111
Ê
"Disabling SVOM boot watchdog functionality" on page 112
Ê
"Shutting down the server" on page 58
Ê
"Disconnecting the power cord" on page 59
Ê
"Getting access to the component" on page 61
Ê
If applicable, remove an expansion card in slot 1 as described in section
"Removing expansion cards from standard slots" on page 300.
14.3.3.2 Removing the defective UFM
Ê
Remove the UFM as described in section "Removing the UFM" on
page 457.
Ê
The UFM spacer remains on the system board.
Upgrade and Repair Unit
(URU)
Hardware: 10 minutes
Software: 5 minutes
Tools:
– Phillips PH1 / (+) No. 1 screw driver
– combination pliers and flat nose pliers
