Fujitsu PRIMERGY TX2560 M2

TX2560 M2 / RX2560 M2 Upgrade and Maintenance Manual 473
System board and components
14.5 SATA DOM
14.5.1 Installing the SATA DOM
14.5.1.1 Preliminary steps
Ê
"Shutting down the server" on page 58
Ê "Disconnecting the power cord" on page 59
Ê "Getting access to the component" on page 61
Ê If applicable, remove the riser module 1 as described in section "Removing
a riser module" on page 98.
14.5.1.2 Installing the SATA DOM
Figure 354: SATA DOM
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
Tools:
tool-less
