Upgrade and Maintenance Manual TX2560 M2 / RX2560 M2
12.7.2 Removing the ultraslim ODD
12.7.2.1 Preliminary steps
Ê
"Removing backup and optical disk media" on page 114
Ê
"Shutting down the server" on page 58
Ê
"Disconnecting the power cord" on page 59
Ê
"Getting access to the component" on page 61
I
The front cover only needs to be removed in order to remove or install
accessible drive dummy covers.
Ê
"Removing the system air duct" on page 91
Ê
"Removing the system fan holder" on page 93
12.7.2.2 Removing the ultraslim ODD adapter
Ê
Remove the ultraslim ODD adapter as described in section "Removing an
accessible drive" on page 402.
12.7.2.3 Removing the ultraslim ODD from the ultraslim ODD adapter
Ê
Disconnect the power cable and the SATA cable from the ultraslim ODD (see
figure 315).
Upgrade and Repair Unit
(URU)
Hardware: 10 minutes
Tools:
Phillips PH0 / (+) No. 0 screw driver
