TX2560 M2 / RX2560 M2 Upgrade and Maintenance Manual 541
Cabling
Figure 416: OOB cable C37
16.4.1 Preliminary steps
Ê "Locating the defective server" on page 55
Ê "Shutting down the server" on page 58
Ê "Disconnecting the power cord" on page 59
Ê "Getting access to the component" on page 61
Ê "Removing the system air duct" on page 91
Ê "Removing the system fan holder" on page 93
16.4.2 Replacing the OOB cable
Ê Disconnect the defective OOB cable from all connectors.
BP1
BP2
BP3
BP4
BP5
BP6
SB
