TX2560 M2 / RX2560 M2 Upgrade and Maintenance Manual 281
Hard disk drive (HDD) / solid state drive (SSD)
7.7.3 Replacing the SAS expander board
7.7.3.1 Preliminary steps
Ê
"Suspending BitLocker functionality" on page 111
Ê "Shutting down the server" on page 58
Ê "Disconnecting the power cord" on page 59
Ê "Getting access to the component" on page 61
Ê "Removing the system air duct" on page 91
Ê "Removing the system fan holder" on page 93
7.7.3.2 Removing the defective SAS expander board
Ê
Remove the SAS expander board as described in section "Removing the
SAS expander board" on page 279.
7.7.3.3 Installing the new SAS expander board
Ê
Install the SAS expander board as described in section "Installing the SAS
expander board" on page 272.
7.7.3.4 Concluding steps
Ê
"Installing the system fan holder" on page 94
Ê "Installing the system air duct" on page 92
Ê "Reassembling" on page 74
Ê "Connecting the power cord" on page 87
Ê "Resuming BitLocker functionality" on page 136
Ê "Switching on the server" on page 90
Field Replaceable Unit
(FRU)
Hardware: 10 minutes
Tools:
tool-less
