Fujitsu PRIMERGY TX2560 M2

TX2560 M2 / RX2560 M2 Upgrade and Maintenance Manual 425
Accessible drives
Ê If the removed ultraslim ODD is not to be replaced by a new drive:
Ê Secure the locking latch to the ultraslim ODD with its two original screws
to the HDD cage (see figure 312).
Ê Insert the ultraslim ODD dummy cover (see figure 311).
12.6.2.4 Installing the 4x 3.5-inch HDD extension box
Ê
Install the 4x 3.5-inch HDD extension box as described in section "Installing
the 4x 3.5-inch HDD extension box" on page 247.
12.6.2.5 Concluding steps
Ê
"Installing the system fan holder" on page 94
Ê "Installing the system air duct" on page 92
Ê "Reassembling" on page 74
Ê "Connecting the power cord" on page 87
Ê "Switching on the server" on page 90
12.6.3 Replacing the ultraslim ODD
12.6.3.1 Preliminary steps
Ê
"Locating the defective server" on page 55
Ê "Removing backup and optical disk media" on page 114
Ê "Shutting down the server" on page 58
Ê "Disconnecting the power cord" on page 59
Upgrade and Repair Unit
(URU)
Hardware: 10 minutes
Tools:
– Phillips PH2 / (+) No. 2 screw driver
– Slotted screw driver (for bending in or out accessible drive
mounting brackets)
