166
Upgrade and Maintenance Manual TX2560 M2 / RX2560 M2
Hard disk drive (HDD) / solid state drive (SSD)
7.2.7 Configuration with up to 24 HDD/SSD modules and
up to 8 PCIe SSDs SFF (six backplanes)
Mounting order
Figure 81: Mounting order for up to 24 HDD/SSD modules and up to 8 PCIe SSDs SFF
[29] 28 Vendor Product (1:28)
[30] 29 Vendor Product (1:29)
[31] 30 Vendor Product (1:30)
[32] 31 Vendor Product (1:31)
Position
Logical drive
number
ServerView RAID Manager display name
(Enclosure number: Port number)
