TX2560 M2 / RX2560 M2 Upgrade and Maintenance Manual
165
Hard disk drive (HDD) / solid state drive (SSD)
I
The HDD/SSD numbering as listed in the ServerView RAID Manager
differs from the HDD mounting order:
With SAS expander board and one SAS controller
Position
Logical drive
number
ServerView RAID Manager display name
(Enclosure number: Port number)
[1] 0 Vendor Product (1:0)
[2] 1 Vendor Product (1:1)
[3] 2 Vendor Product (1:2)
[4] 3 Vendor Product (1:3)
[5] 4 Vendor Product (1:4)
[6] 5 Vendor Product (1:5)
[7] 6 Vendor Product (1:6)
[8] 7 Vendor Product (1:7)
[9] 8 Vendor Product (1:8)
[10] 9 Vendor Product (1:9)
[11] 10 Vendor Product (1:10)
[12] 11 Vendor Product (1:11)
[13] 12 Vendor Product (1:12)
[14] 13 Vendor Product (1:13)
[15] 14 Vendor Product (1:14)
[16] 15 Vendor Product (1:15)
[17] 16 Vendor Product (1:16)
[18] 17 Vendor Product (1:17)
[19] 18 Vendor Product (1:18)
[20] 19 Vendor Product (1:19)
[21] 20 Vendor Product (1:20)
[22] 21 Vendor Product (1:21)
[23] 22 Vendor Product (1:22)
[24] 23 Vendor Product (1:23)
[25] 24 Vendor Product (1:24)
[26] 25 Vendor Product (1:25)
[27] 26 Vendor Product (1:26)
[28] 27 Vendor Product (1:27)
