244
Upgrade and Maintenance Manual TX2560 M2 / RX2560 M2
Hard disk drive (HDD) / solid state drive (SSD)
Ê
"Connecting the power cord" on page 87
Ê
"Resuming BitLocker functionality" on page 136
Ê
"Switching on the server" on page 90
7.4.4 Replacing the HDD/SSD backplane on the
8x 2.5-inch HDD extension box
7.4.4.1 Preliminary steps
Ê
"Shutting down the server" on page 58
Ê
"Disconnecting the power cord" on page 59
Ê
Remove all HDD modules from the HDD extension box as described in
section "Removing 2.5-inch HDD/SSD modules" on page 175.
Ê
"Getting access to the component" on page 61
Ê
"Removing the system air duct" on page 91
Ê
"Removing the system fan holder" on page 93
7.4.4.2 Removing the defective HDD/SSD backplane
Ê
Unlock and pull the 8x 2.5-inch HDD extension box out of its installation bays
as described in section "Removing the 8x 2.5-inch HDD extension box" on
page 242.
Upgrade and Repair Unit
(URU)
Hardware: 10 minutes
Tools:
Phillips PH2 / (+) No. 2 screw driver
