376
Upgrade and Maintenance Manual TX2560 M2 / RX2560 M2
Ê
Install the heat sinks as described in section "Installing heat sinks" on
page 385.
11.2.4 Concluding steps
Ê
"Installing the system air duct" on page 92
Ê
"Reassembling" on page 74
Ê
Reconnect all external cables.
Ê
"Connecting the power cord" on page 87
Ê
"Switching on the server" on page 90
Ê
If available, "Updating or recovering the system board BIOS and iRMC" on
page 119
Ê
"Enabling SVOM boot watchdog functionality" on page 130
Ê
"Resuming BitLocker functionality" on page 136
11.3 Removing CPUs
V CAUTION!
CPU
s are extremely sensitive to electrostatic discharge and must be
handled with care. After a
CPU
has been removed from its protective sleeve
or from its socket, place it upside down on a nonconducting, antistatic
surface. Never push a
CPU
over a surface.
Upgrade and Repair Unit
(URU)
Hardware: 15 minutes
Software: 5 minutes
Tools:
– Phillips PH2 / (+) No. 2 screw driver
– nut driver size 6mm
