Main memory
– In order to satisfy cooling requirements, populate memory channels on
alternating sides of the CPU:
10.2 Installing memory modules
10.2.1 Preliminary steps
Ê "Suspending BitLocker functionality" on page 111
Ê "Disabling SVOM boot watchdog functionality" on page 112
Ê "Shutting down the server" on page 58
Ê "Disconnecting the power cord" on page 59
Ê "Getting access to the component" on page 61
Ê "Removing the system air duct" on page 91
Order CPU 1 CPU 2
1 Channel A Channel E
2 Channel C Channel G
3 Channel B Channel F
4 Channel D Channel H
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
Tools:
tool-less
