TX2560 M2 / RX2560 M2 Upgrade and Maintenance Manual
345
Expansion cards and backup units
9.6 Serial interface
9.6.1 Installing the serial interface
I
The slot brackets contained in the kit are not used in this server.
9.6.1.1 Preliminary steps
Ê
"Disabling SVOM boot watchdog functionality" on page 112
Ê
"Shutting down the server" on page 58
Ê
"Disconnecting the power cord" on page 59
Ê
"Getting access to the component" on page 61
9.6.1.2 Installing the serial interface
Figure 252: Breaking out the metal plate
Ê
If applicable, break out the metal plate.
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
Tools:
– flat screw driver
– nut driver 5 mm
