Fujitsu PRIMERGY TX2560 M2

412 Upgrade and Maintenance Manual TX2560 M2 / RX2560 M2
Accessible drives
Figure 304: Removing the Multibay box
Ê Carefully pull the Multibay box out of its installation bay (1).
Ê Close the locking bar (2) until it locks in place (3).
12.5.2.3 Removing the slimline ODD from the Multibay box
Figure 305: Removing the slimline ODD from the Multibay box
Ê Press up on the locking tab to disengage the slimline ODD module (1).
