Upgrade and Maintenance Manual TX2560 M2 / RX2560 M2
System board and components
14.5.3 Replacing the SATA DOM
14.5.3.1 Preliminary steps
Ê
"Locating the defective server" on page 55.
Ê
"Shutting down the server" on page 58.
Ê
"Disconnecting the power cord" on page 59.
Ê
"Getting access to the component" on page 61
Ê
If applicable, remove the riser module 1 as described in section "Removing
a riser module" on page 98.
14.5.3.2 Replacing the SATA DOM
Ê
Remove the defective SATA DOM as described in section "Removing the
SATA DOM" on page 475.
Ê
Install the new SATA DOM as described in section "Installing the SATA
DOM" on page 473.
14.5.3.3 Concluding steps
Ê
If applicable, install the riser module 1 as described in section "Installing a
riser module" on page 95.
Ê
"Reassembling" on page 74
Ê
"Connecting the power cord" on page 87
Ê
"Switching on the server" on page 90
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
Tools:
tool-less
