TX2560 M2 / RX2560 M2 Upgrade and Maintenance Manual
337
Expansion cards and backup units
9.5.2.2 Removing the slot cover
Figure 245: Removing the dummy cover
Ê
Grip the handle and pull out the dummy cover.
Figure 246: Removing the system board screw
Ê
Remove the system board screw (see circle).
