Fujitsu PRIMERGY TX2560 M2

564 Upgrade and Maintenance Manual TX2560 M2 / RX2560 M2
Appendix
17.2.3.3 Indicators on PSUs (slide-in units)
Figure 431: PSU status indicator
Pos. Indicator Status Description
1
PSU status
indicator
green flashing The server is switched off, but mains
voltage is present (standby mode).
green on The server is switched on and operating
properly.
orange
flashing
An overload has been detected. The PSU
is still running, but failure might be
imminent.
orange on
An PSU failure has been detected.
Possible causes:
– Over/under voltage
– Overheating
– Fan failure
