Fujitsu PRIMERGY TX2560 M2 Upgrade And Maintenance Manual

146 Upgrade and Maintenance Manual TX2560 M2 / RX2560 M2
Power supply unit (PSU)
6.2 Installing a PSU
6.2.1 Preliminary steps
No steps needed.
6.2.2 Removing the PSU dummy module
Figure 64: Removing a PSU dummy module
Ê Press in on both locking latches on the PSU dummy module (1) and carefully
detach the dummy module from its slot.
Ê Remove the dummy module from its slot (2).
V CAUTION!
Keep the dummy cover for future use. If a PSU is removed and not
immediately replaced by a new one, a PSU dummy cover must be
replaced in the slot to comply with applicable EMC regulations and
satisfy cooling requirements.
Customer Replaceable Unit
(CRU)
Hardware: 5 minutes
Tools:
tool-less
