TX2560 M2 / RX2560 M2 Upgrade and Maintenance Manual
553
F - PCI card off PCI card okay
orange on PCI card failure (PCI card installed on riser
card)
G - CPU off CPU okay
orange on CPU failure
H - Memory off memory module running
orange on memory module failure
I -
MBC PWR OK
green on Power supply ok
K -
MBC ERROR
orange on Power supply error
L - Main Power green on PWROK
M - Standby
Power
yellow on PWROK STBY
N - iRMC off iRMC S4 inactive
green flashing iRMC S4 okay
O - Fan off Fan running
orange on Fan failure
P - Battery orange on Battery failure
LED Indicator Meaning
