552 Upgrade and Maintenance Manual TX2560 M2 / RX2560 M2
Appendix
Using the Indicate LDL button
Ê
Shut down and power off the server.
Ê Disconnect the AC power cords from the system.
I It is mandatory to disconnect power cords in order to use the Indicate
LDL functionality.
Ê Remove the air duct as described in section "Removing the system air duct"
on page 91.
Ê Press the Indicate LDL button (1) to highlight defective components.
Onboard indicators
The LEDs have the following meaning:
LED Indicator Meaning
A - Identification
blue on
The server has been highlighted using
ServerView Operations Manager, iRMC web
frontend or the ID button on the front panel
for easy identification
blue flashing
The server has been highlighted for easy
identification using the iRMC (AVR) with
disabled local VGA output.
B - CSS
(Customer Self
Service)
off No critical event detected (CSS component).
orange on Prefailure event detected (CSS component).
orange flashing CSS component failure detected.
C - GEL
(Global Error
LED)
off
No critical event detected (non CSS
component).
orange on
Prefailure event detected (non CSS
component).
orange flashing
Non CSS component failure detected.
Possible causes:
– System is out of the specified
temperature range
– Defective sensor
– CPU error
– Error detected by server management
software
