Fujitsu PRIMERGY TX2560 M2

TX2560 M2 / RX2560 M2 Upgrade and Maintenance Manual 157
Hard disk drive (HDD) / solid state drive (SSD)
Figure 71: Example five backplanes
I This numbering is based on "Configuration with up to 32 HDD/SSD
modules (five backplanes)" on page 164.
1 SAS backplane 1 in HDD cage 1 (basic configuration)
2 SAS backplane 2 in HDD cage 2 (basic configuration)
3 SAS backplane 3 in HDD cage 1 (basic configuration)
4 SAS backplane 4 in HDD cage 2 (basic configuration)
5 SAS backplane 5 in optional 8x 2.5-inch HDD extension box
