Fujitsu PRIMERGY TX2560 M2

TX2560 M2 / RX2560 M2 Upgrade and Maintenance Manual 217
Hard disk drive (HDD) / solid state drive (SSD)
I The HDD numbering as listed in the ServerView RAID Manager differs
from the HDD mounting order:
With SAS expander board and one SAS controller
(Based on cabling "SAS cabling: 2x 2.5" non-hot-plug HDDs/SSDs / 12x 3.5"
HDDs and SAS 3.0 expander board A3C40181407" on page 521)
Position
Logical drive
number
ServerView RAID Manager display name
(Enclosure number: Port number)
[1] 0 Vendor Product (1:0)
[2] 1 Vendor Product (1:1)
[3] 2 Vendor Product (1:4)
[4] 3 Vendor Product (1:5)
[5] 4 Vendor Product (1:6)
[6] 5 Vendor Product (1:7)
[7] 6 Vendor Product (1:8)
[8] 7 Vendor Product (1:9)
[9] 8 Vendor Product (1:10)
[10] 9 Vendor Product (1:11)
[11] 10 Vendor Product (1:12)
[12] 11 Vendor Product (1:13)
[13] 12 Vendor Product (1:14)
[14] 13 Vendor Product (1:15)
