TX2560 M2 / RX2560 M2 Upgrade and Maintenance Manual
301
Expansion cards and backup units
Figure 209: Removing the air duct - PCI slot 1 (A)
Ê
Only for PCI slot 1: lift up the locking handle on the air duct (see circle in
close-up) while sliding the air duct in direction of the arrow.
Figure 210: Removing the air duct - PCI slot 1 (B)
Ê
Only for PCI slot 1: remove the air duct.
