Upgrade and Maintenance Manual TX2560 M2 / RX2560 M2
Figure 269: Closing the load plate (A)
Ê
Carefully lower the load plate over the CPU.
Figure 270: Closing the load plate (B)
Ê
Fully fold back the socket release lever marked
Close 1st
until the bail on the
lever (A) catches the latch on the load plate (see close-up).
