Fujitsu PRIMERGY TX2560 M2

38 Upgrade and Maintenance Manual TX2560 M2 / RX2560 M2
Before you start
Dedicated TPM
screw driver /
TPM module
fixing tool
0.6 Nm
TPM
REM 3 x 15 mm
(black)
C26192-Y10-C176
Phillips
PH1 / (+) No. 1
0.06 Nm
UFM
M3 x 4.5 mm
(white)
A3C40109082
Phillips
PH1 / (+) No. 1
0.4 Nm
TFM
M2.5 x 4 mm
(silver)
C26192-Y10-C103
Hexagon bolt
0.6 Nm
Front VGA
connector,
serial
interface
UNC #4-40
(silver)
V26827-B408-V989
SW5
0.6 Nm
DynamicLoM
module
(D3245,
D3255)
M3 x 5 mm
(silver)
C26192-Y1-C65
SW5
0.6 Nm
DynamicLoM
module
(D3265,
D3275,
D3285)
M3 x 8 mm
(silver)
C26192-Y1-C66
Screw driver /
Bit insert
Torque
Screw Usage Type
Table 3: List of used screws (Japanese market)
