Fujitsu PRIMERGY TX2560 M2

TX2560 M2 / RX2560 M2 Upgrade and Maintenance Manual 525
Cabling
Figure 395: SAS cabling: 24x 2.5" HDDs and accessible drives and SAS 3.0 expander board
A3C40176099
8x 2.5" HDD
Backplane 3
X9
4x 2.5" HDD
Backplane 2
X9
C11
C11
C11
System Board
SATA 5
USB 3.0 INT
SAS 3.0 Ctrl
Slot 1 (boot)
MLC2
MLC1
C10
C10
X10
C11
SAS 3.0
Expander
X15
X14
X13
X12
X11
X10
X2
X1
X17
X16
X3
8x 2.5" HDD
Backplane 4
X9
X10
C11
C11
4x 2.5" HDD
Backplane 1
X9
SAS 3.0 Ctrl
Slot 2/3
MLC2
MLC1
SAS Backup Drive
USB Backup Drive
Optical Disk Drive
X17
C21
C20
C3
