Fujitsu PRIMERGY TX2560 M2

530 Upgrade and Maintenance Manual TX2560 M2 / RX2560 M2
Cabling
Figure 401: Options: OOB for three HDD backplanes and PSAS HBA
Figure 402: Options: OOB for six HDD backplanes and PSAS HBA
System Board
I2C5
C36
3.5/2.5" HDD
Backplane 3
X11
3.5/2.5" HDD
Backplane 2
X11
3.5/2.5" HDD
Backplane 1
X11
SB
BP1
BP2
BP3
BP4
System Board
I2C5
C37
2.5" HDD
Backplane 3
X11
2.5" HDD
Backplane 2
X11
2.5" HDD
Backplane 1
X11
HDD Extension Box
2.5" HDD
Backplane 4
X11
3.5/2.5" HDD
Backplane 5
X11
2.5" HDD
Backplane 6
X11
SB
BP1
BP2
BP3
BP4
BP5
BP6
