TX2560 M2 / RX2560 M2 Upgrade and Maintenance Manual
99
Basic hardware procedures
Figure 50: Removing riser module - example riser module 1
Ê
Remove the three screws inside the chassis (1, see circles).
Ê
Carefully take out the riser module (2).
