Philips Azurion - 6.16.4 XperCT Dual

Protocol Speed [fps]
Duraon [s]
(appr
oximate) Posion Contrast
XperCT Dual Prop (open) LD - 5s 60 5 Head Low
XperCT Prop open - 4s 60 4 Head Low
XperCT Roll - 8s 60 8 Side High
XperCT Dual Roll - 8s 60 8 Side High
VasoCT I.A. 22 cm / 8.5" 30 21 Head High
VasoCT I.A. 27 cm / 10.5" 30 21 Head High
VasoCT I.V. 22 cm / 8.5" 30 21 Head High
VasoCT I.V. 27 cm / 10.5" 30 21 Head High
HD = High Dose, LD = Low Dose, ( ) = oponal
NOTE Some of these applic
aon protocols may not be available, depending on the X-ray equipment
in use and the purchased opons.
6.16.4 XperCT Dual
The XperCT Dual procedure is a dual phase scan that consists of a forward phase and a backward
phase. The acquired images are automacally sent to the Intervenonal Tools workstaon.
Contrast is used during the forward phase of the scan to visualize the arteries. Aer a brief pause,
known as the scan interval, the backward phase is acquired. While the contrast medium has washed
out of the arteries, the lesion holds the contrast medium for slightly longer, allowing the lesion to be
visualized in the backward phase.
For informaon about XperCT calibraon, see XperCT Calibraon (page 263).
NOTE You must be logged on to the Intervenonal Tools workstaon before starng the acquision.
We recommend that you switch the workstaon on and log on at the start of your work
schedule to avoid a delay.
NOTE If the exposure switch is released aer the forward scan, the backward scan is canceled.
NOTE BodyGuards are disabled during image acquision.
1 Posion the C-arm in the working posion.
2 Posion the region of interest in the isocenter.
For more informaon, see Isocentering (page 90).
3 Select the X-ray Sengs task.
4 Select the XperCT Dual Phase procedure.
5 Adjust the interval me if desired.
6 From the control module, posion the detector in the landscape posion.
7 Select the maximum source-to-image distance.
8 Clear all objects from the rotaonal arc of the C-arm.
9 Switch Injector Coupling on or o as desired.
a If you switch Injector Coupling on, set the X-ray delay me.
10 Follow the instrucons given on the touch screen module to conrm the end posion.
Performing Procedures Rotaon Sc
ans
Azurion Release 1.2 Ins
trucons for Use 107 Philips Healthcare 4522 203 52421
