Philips Azurion - Sphere Calibration

8 Y
ou can delete the calibraon at any me and start over by clicking Delete in the task panel.
9 To complete manual calibraon, click Accept and Close.
Sphere Calibraon
You perform sphere calibraon by idenfying a sphere of a known size in the image.
1 In the Calibraon and Measurements task panel, click Manual Calibraon to display the
Calibraon dialog box.
2 In the Cal. Method list, select Sphere.
3 If you want to change the series on which to perform calibraon, click Change and select an
available series.
The currently selected series is used by default. The selected series number is displayed in the task
panel.
4 Click Draw in the control panel.
5 Click a sphere in the image to idenfy it.
6 To hide or show the sphere contour, select or clear Hide in the control panel.
7 To edit the sphere, click Edit in the control panel, and do any of the following:
• To move the sphere, drag the center of the sphere to a new posion.
• To change the diameter of the sphere, drag the circumference of the sphere.
8 When the sphere is dened, select the diameter in the list in the control panel.
If the desired diameter is not available, you can type it directly in the box.
9 You can delete the calibraon at any me and start over by clicking Delete in the task panel.
10 To complete manual calibraon, click Accept and Close.
Processing Creang Measur
ements
Azurion Release 1.2 Ins
trucons for Use 146 Philips Healthcare 4522 203 52421
