NOTE The connected supply shall be compliant with NEMA standard XR9 - Power Supply Guideline
f
or X-ray machines.
NOTE
Input wiring shall be at least 6AWG (13.3 mm
2
).
Addional E
quipment
Equipment Mains Voltage Mains Frequency Maximum Power Consumpon
Wireless Foot Switch Charger 100 - 240 V AC 50 / 60 Hz 26 W
XperGuide Laser Tool Charger 100 - 240 V AC 50 / 60 Hz 6 W (approximately)
Wall Connecon Bo
x 100 - 240 V AC 50 / 60 Hz 40 W
Equipment Rack 100 - 240 V AC 50 / 60 Hz 3680 W
16.6 Monitor Ceiling Suspension
W
eight, Load, and Dimensions
MCS Max. total weight (kg) Width x Height x Depth (mm)
2-fold 115 850 x 590 x 400 (monoplane only)
4-fold 155 1250 x 1150 x 524
6-fold 180 1424 x 1150 x 524
Movement Range
Mo
vement ranges are approximate.
MCS Longitudinal (mm) Lateral (mm)
Vercal (mm)
Ceiling height 2900 mm
2-fold 3600 3000 520 (monoplane only)
4-fold 3600 3000 320
6-fold 3600 3000 320
Actuator
Item Specicaon
Mains voltage 230 V
Mains frequency 50 / 60 Hz
Maximum power c
onsumpon 500 W
Maximum speed 12 mm/s (0.5 in/s)
16.6.1 FlexVision (XL) Monitor Ceiling Suspension
Dimensions and W
eight
MCS Width [mm] Height [mm] Depth [mm] Weight [kg]
1-fold (XL) 1750 1150 250 220
3-fold (XL) 1750 1450 250 260
Technical In
formaon Monitor Ceiling Suspension
Azurion Release 1.2 Ins
trucons for Use 275 Philips Healthcare 4522 203 52421
