10.8.2 Changing QCA / QVA Default Curve Display Sengs
1 On the S
ystem menu, click Customizaon.
2 On the le side of the screen, in the Measurements and Analysis secon, click Calibraon and
Vessel Analysis.
3 Change the following seng, as desired:
Item Sengs
Default Curve Display Diameter
Diameter & Area
4 Click Sa
ve to save your changes.
10.8.3 Changing LVA Default Sengs
1 On the System menu, click Customizaon.
2 On the le side of the screen, in the Measurements and Analysis secon, click Le Ventricle
Analysis.
3 Change the following sengs, as desired:
Item Sengs Notes
Default Index method BSA The cardiac output is always indexed
t
o BSA, irrespecve of the selected in-
dex method.
BSA^1.219
Weight
Monoplane Volume Method List Area Length
Simpson
Monoplane Regression Formulas Area Length
RAO30, EDV, ESV = 0.783, Vcalc = –3.759, Adults/Children
RAO30, EDV, ESV = 0.810, Vcalc = 1.9, Adults/Children
RAO30, EDV, ESV = 0.822, Vcalc = 0, Adults/Children
Simpson
RAO30, EDV, ESV = 0.737, Vcalc = –4.649, Adults/Children
You can select a predened regression formula, or you can enter a user-dened
formula in the boxes provided.
Biplane Volume Method List Area Length
Biplane Regression Formulas RAO30/LAO60, EDV, ESV = 0.989, Vcalc = –8.1, Adults/Children
You can select a predened regression formula, or you can enter a user-dened
formula in the boxes provided.
Rotaon Range Enter a range in the boxes in which warnings are suppressed.
Angulaon Range Enter a range in the boxes in which warnings are suppressed.
4 T
o undo any changes that you have made in the Le Ventricle Analysis panel, click Undo Changes.
5 Alternavely, to restore the system sengs to default values, click Reset Default.
Item Default Sengs Input Range
Default index method BSA Not applicable
2D Quant
ave Analysis (Opon) 2D-QA Sengs
