Philips Azurion - 7.3 Reviewing a Series using the Touch Screen Module

1 Click the Series t
ask in the review window to select a series for review.
2 To change the way series are listed in the control panel, do one of the following:
• Click Show pictorials to display the series as pictorials.
• Click Show details to display the series as a list.
3 Do one of the following:
• Click a series to open it in the main display area.
• Double-click a series to open it in the main display area and automacally replay the images in
the series.
NOTE Biplane series are always displayed with the frontal series and lateral series side by side
in the Series task. When you select a biplane series, the corresponding series on the other
channel is also selected.
4 To control the replay of the images in a series, do the following:
a To replay the series, click Play.
b To pause the series, click Pause
c To review the previous or next image in the series, click Previous image or Next image.
d T
o review the previous or next series, click Previous series or Next series.
e T
o change the frame rate used when replaying the images, click Frame Rate and adjust the
slider to the desired number of images per second.
NOTE When reviewing biplane images, only one movie toolbar is displayed. Movie playback
and displayed images are synchronized for the frontal and lateral images.
5 To replay all images and series in the study, click Cycle All.
6 To display an overview of all images in the selected series, click Image Overview.
7 To display one image from each of the available series for the paent, click Series Overview.
8 To review a parcular type of image, select one of the following lters from the list:
• Acquired images
• Photo images
• Flagged images
7.3 Reviewing a Series using the Touch Screen Module
You can review a series for the acquision paent using the touch screen module.
Reviewing Reviewing a Series using the Touch Screen Module
Azurion Release 1.2 Ins
trucons for Use 118 Philips Healthcare 4522 203 52421
