8.1 Zooming
Y
ou can zoom images using the mouse or the touch screen module. When using the mouse, you can
zoom images in the acquision window and the review window. When using the touch screen module,
you can zoom images in the acquision window.
1 Select the Processing task, and then click or tap Zoom and Pan.
NOTE Zoom is also available on the toolbar in the acquision window or review window.
2 To zoom using the mouse, do the following:
• To zoom in, drag upward.
• To zoom out, drag downward.
a To zoom the current image only, select Adjust current image only in the control panel.
3 To zoom using the touch screen module, use the Zoom controls.
NOTE You can also zoom with touch gestures on the touch screen module. For more
inf
ormaon, see Touch Screen Gestures (page 358).
a To select whether your changes apply to the current image only or to all images, tap Scope and
select an opon.
–
Apply changes to the current image only.
–
Apply changes to all images in the series.
4 T
o display the complete image in the center of the view again, click or tap Reset in the control
panel.
8.2 Panning
You can pan images using the mouse or the touch screen module. When using the mouse, you can pan
images in the acquision window and the review window. When using the touch screen module, you
can pan images in the acquision window. Panning allows you to view dierent areas of a zoomed
image.
1 Select the Processing task, and then click or tap Zoom and Pan.
NOTE Pan is also available on the toolbar in the ac
quision window or review window.
2 To pan using the mouse, drag the image in the desired direcon.
a To pan the current image only, select Adjust current image only in the control panel.
3 To pan using the touch screen module, use the Pan controls.
