Philips Azurion - 16.10 Detectors

16.10 Detectors
C12/F12
Item Specicaon
Detector 30 cm (11.6 inch) diagonal square, triple mode a
t detector
subsystem
Image format (available at all source-to-image posions) 30 cm (11.6 inch)
27 cm (10.5 inch)
22 cm (8 inch)
19 cm (7 inch)
15 cm (6 inch)
Pixel size 154 x 154 µm
Detecve quantum eciency (DQE) 77% at 0 lp/mm
Spaal resoluon properes: MTF: 1.0 lp/mm >60%
Nyquist: 3.25 lp/mm
Dynamic range Linear within 2% from 2500 nGy in uoroscopy mode to
50000 nGy in exposure mode (dependent upon operang
mode)
Output digital video 30 cm 1340 x 1340 664 x 664
27 cm 1232 x 1232 960 x 960
22 cm 1016 x 1016 508 x 508
19 cm 864 x 864 432 x 432
15 cm 720 x 720 360 x 360
Geometrical ll factors Photodiode (opcal ll factor): 63%
Scinllator (X-ray ll factor): 100%
F15
Item Specicaon
Detector 26 x 33 cm (10 x 13 inch) 7 mode Flat Detector subsystem
Image format (available at all source-to-image posions) 39 cm (15.2 inch)
37 cm (14.4 inch)
31 cm (13 inch)
27 cm (10.5 inch)
22 cm (8 inch)
19 cm (7 inch)
15 cm (6 inch)
Pixel size 184 x 184 µm
Detecve quan
tum eciency (DQE) 70% at 0 lp/mm
Spaal resoluon properes: MTF:
• 1.0 lp/mm >60%
• 2.0 lp/mm >30%
Nyquist: 3.25 lp/mm (>15%)
Dynamic range Linear within 2% up to 4300 nGy
Output digital video 39 cm 2000 x 1688 1000 x 844
37 cm 1688 x 1688 844 x 844
31 cm 1340 x 1340 664 x 664
27 cm 1232 x 1232 960 x 960
22 cm 1016 x 1016 508 x 508
19 cm 864 x 864 432 x 432
15 cm 720 x 720 360 x 360
Technical In
formaon Detectors
Azurion Release 1.2 Ins
trucons for Use 278 Philips Healthcare 4522 203 52421
