Philips Azurion - 16.12 Beam Carriers with FlexMove

Item Specicaon
Isocenter to oor 106.5 cm (41.93 inch)
Focal spot to isocenter 81 cm (31.9 inch)
Focal spot to detector (source-to-image distance) 89.5 to 119.5 cm (35.2 to 47 inch)
Detector movement speed Toward the paen
t: 10 cm/s
Away from the paent: 15 cm/s
Throat depth 90 cm (35.4 inch)
Longitudinal movement (manual or motorized) 260 cm (102.4 inch)
With extended ceiling rail (opon): 410 cm (161.4 inch)
Motorized longitudinal movement speed (opon) 15 cm/s
Motorized stand rotaon 90 degrees le to 90 degrees right at 12 degrees/s
Rotaon scan Propeller movement: From 185 degrees RAO (-rotaon) to
120 degrees LAO (+rotaon) at a speed of up to 55
degrees/s
Roll movement: From 90 degrees LAO to 90 degrees RAO at
a speed of up to 30 degrees/s
Minimum ceiling height 270 cm (106 inch)
Lateral Beam Carriers for Biplane Systems
Item Specicaon
Detector size 12-inch (FD12) or 15-inch (FD15)
Detector orien
taon Fixed (non-rotatable)
Rotaon speed 8 degrees/s (also for combined frontal and lateral move-
ments)
Angulaon speed 8 degrees/s
Roll angle L-arc C: 0 degrees to +90 degrees
L-arc N: -115 degrees to -27 degrees
Propeller angle (skew) -45 degrees to +45 degrees
Isocenter to oor (depending on the system in use) F12/12: 106.5 cm (41.9 inch)
F20/12: 114.0 cm (44.9 inch)
F20/15: 114.0 cm (44.9 inch)
Focal spot to detector (source-to-image distance) FD12: 87.8 to 130.6 cm (34.6 to 51.4 inch)
FD15: 87.4 to 130.2 cm (34.4 to 51.3 inch)
Detector movement speed Toward the paent: 6 cm/s
Away from the paent: 9 cm/s
Longitudinal movement (manual or motorized) 315 cm (124 inch)
Motorized longitudinal movement speed (opon) Outside the working area: 12 cm/s
Inside the working area: 6 cm/s
16.12 Beam Carriers with FlexMove
C20/F20 S
ystems
The X-ray beam eld is always aligned with the image receptor area and the reference axis is always
perpendicular to the image receptor plane.
Item Specicaon
Rotaon speed 0 - 25 degrees/s (variable)
These speeds ar
e only valid when the stand is in its working
posion, otherwise the maximum speed is 8 degrees/s
Technical In
formaon Beam Carriers with FlexMove
Azurion Release 1.2 Ins
trucons for Use 282 Philips Healthcare 4522 203 52421
