18.5.1 Status Area - Monoplane System
On a monoplane s
ystem, the status area is visible on the acquision window in the control room and in
the live X-ray window in the examinaon room.
Status Area in the Control Room (Monoplane System)
Figure 185 St
atus area in the control room acquision window
Legend Descripon
1
System status The system is ready for exposure.
System status The system is not ready for exposure.
2
X-ray status X-ray is on.
X-ray status X-ray is disabled.
3 Tube load The tube is overheated.
4
Fluoroscopy Fluoroscopy sengs ar
e displayed.
Exposure Exposure sengs ar
e displayed.
- kV
X-ray generator sengs- mA
- ms
Quick Reference Status Area
Azurion Release 1.2 Ins
trucons for Use 359 Philips Healthcare 4522 203 52421
