12 Pr
ess and hold Accept on the control module unl the C-arm reaches the end posion.
13 Press and hold Accept on control module unl the C-arm reaches the start posion.
14 If injector coupling is switched on, prepare the injector.
The system is now ready to acquire images.
15 Instruct the paent.
16 Start acquision by pressing the hand switch unl exposure stops.
NOTE BodyGuards are disabled during image ac
quision.
CardiacSwing Procedure Selecon
For CardiacSwing procedures, the recommended eld of view is 30 cm (11.6 inch) for C12/F12 systems,
and 27 cm (10.5 inch) or greater for F15 and C20/F20 systems.
To opmize imaging, the artery should be lled from rst to last image of the swing procedure. It is
recommended to begin the injecon 0.5 seconds prior to acquision of the rst image. If you are using
a power injector set an X-ray delay me on the system for 0.5 seconds.
All procedures are performed with the following sengs:
• C-arm posion: head end
• Framerate: 15 fps or 25 fps
Procedure
Exposure Time
[seconds]
Injecon Duraon
[seconds] Clinical Area
LCA CRA 30 5s 5.3 5.8 Le coronary
LCA CRA 35 5s
(Best pracce)
5.8 6.3 Le coronary
LCA CRA 40 5s
F12 system only
5.8 6.3 Le coronary
RCA LAO 3s 3.7 4.2 Right coronary
RCA AP 4s
(Best pracce)
4.1 4.5 Right coronary
LCA/RCA RAO-CAU -> LAO-
CRA 4s
4.1 4.6
Le coronary
Right coronary
Gras
LCA/RCA LAO-CAU -> RAO-
CRA 4s
4.1 4.6
Le coronary
Right coronary
Gras
Performing Procedures Rotaon Sc
ans
