• You must cover the equipment thoroughly with plasc sheeng be
fore using disinfectant sprays.
• When all traces of disinfectant vapor have dispersed, you can remove the plasc sheeng and
disinfect the equipment in the recommended way.
14.1.1 Cleaning the Ceiling Rails
The ceiling rails should be cleaned according to the planned maintenance program to prevent dust and
debris from being released from the rails and pollung the air ow around the table. Polluted air and
contaminated parts of the X-ray system may infect the paent.
1 Clean the ceiling rail track to remove dirt.
Insucient cleaning may result in clots of dirt that degrade the performance of longitudinal
movements.
2 When present, check the xaon of the longitudinal brake strip and clean the strip with alcohol.
14.2 Removing and Replacing the An-Scaer Grid
This procedure provides guidance for removing and replacing the an-scaer grid.
To prevent damage to the grid, observe the following guidance:
• Do not drop the grid.
• Do not apply excessive force to the grid.
• Do not use the grid to carry objects.
• Do not expose the grid to temperatures above 40°C (104°F).
• Do not store the grid in direct sunlight or near heat sources such as heaters or cooling fan outlets.
• Do not store the grid in cabinets with heat dissipang components.
• Do not sterilize the grid, or immerse it in water.
• Do not expose the grid to steam cleaners.
14.2.1 Removing the An-Scaer Grid
Take care to avoid damaging either the detector or the an-scaer grid during the following procedure.
Figure 125 R
emoving the an-scaer grid
1 Rotate the C-arm to the lateral posion shown in the gure below.
Maintenance Removing and Replacing the An-Sc
aer Grid
