Figure 117 R

ear interface panel on the rear side of the table base

Connectors

1 Potenal equaliz

aon points Ground (earth) connecon points (x4)

2 Injector connecon (oponal) A connector can be installed in this posion for a rack-mounted injector

(if a connector is not installed, a blanking plate is used)

3 Foot switch connectors Connectors for the foot switches

4 28-pin connector Connector for pedestal-mounted injectors.

5 23-pin connector Connector for external ECG and Physio equipment

6 Secondary circuit outlet connector 230 V (50/60 Hz)

Figure 118 R

ear interface panel under the tabletop

Table Base Accessory Rail

The table base accessory rail can carry equipment up to 10 kg. The maximum torque load (moment) is

30 Nm.

Using Other Equipment Other Devices

Azurion Release 1.2 Ins

trucons for Use 210 Philips Healthcare 4522 203 52421
