Philips Azurion - 8.6.2 Adding an Arrow; 8.6.3 Adding an Ellipse

6 T
o move an annotaon, drag it to a new locaon.
7 To delete an annotaon, select the annotaon, and then click Delete in the task panel.
You can also delete an annotaon (or just an annotaon's text label, if applicable) from the shortcut
menu aer right-clicking the annotaon.
8.6.2 Adding an Arrow
You can add an arrow annotaon with a text label.
1 Click the Processing task, and then click Annotaons to display the available opons.
2 To apply an annotaon to all images in the series, instead of just the selected image, select
Annotate All Images in the task panel before creang the annotaon.
3 Click Arrow + Text in the task panel.
4 Click in the image at the locaon where you want to place the point of the arrow, and then click
again at the end of the arrow.
5 Do one of the following:
• Type your own text in the label, and then press Enter or click outside the label.
• Click the arrow at the end of the label and select a predened annotaon.
• To create the annotaon without a text label, press Enter or click outside the label without
entering any text.
NOTE To edit a text label aer creang an annotaon, click the label, and then edit the text.
6 To change the appearance of an annotaon, right-click it and select an opon from the shortcut
menu.
You can change the following characteriscs, when available:
• Color
• Font Size
• Line Thickness
7 To move an arrow or its text label, drag it to a new locaon.
8 To edit an arrow, drag an end point to a new locaon.
9 To delete an annotaon, select the annotaon, and then click Delete in the task panel.
You can also delete an annotaon (or just an annotaon's text label, if applicable) from the shortcut
menu aer right-clicking the annotaon.
8.6.3 Adding an Ellipse
1 Click the Processing task, and then click Annotaons to display the available opons.
2 Click Ellipse in the task panel, and then do the following (creang an ellipse requires three mouse
clicks):
• In the image, click to start drawing the ellipse.
• Move the pointer and click to set the length (long axis) of the ellipse.
• Click again to set the width (short axis) of the ellipse.
3 To change the appearance of an annotaon, right-click it and select an opon from the shortcut
menu.
Processing Adding Annot
aons
Azurion Release 1.2 Ins
trucons for Use 134 Philips Healthcare 4522 203 52421
