16 Technical In
formaon
The following secons provide informaon and data tables about the specicaon of the system.
16.1 Environmental Requirements
Operaon
Environmental Condion Range (Minimum to Maximum)
Ambient temperature +10°C to +30°C (59°F to + 86°F)
Relave humidity 20% to 80%
Pressure 70 kPa to 106 kPa (0 to 3000 m altude)
(700 hP
a to 1060 hPa)
NOTE To allow unrestricted air o
w around the cabinets of the system, do not place any items on
top of the cabinets.
Transport and storage
Environmental Condion Range (Minimum to Maximum)
Temperature -20°C to +75°C (-4°F to 167°F)
Relave humidity 10% to 90%
Pressure 70 kPa to 106 kPa (0 to 3000 m altude)
(700 hP
a to 1060 hPa)
Equipment IP Rangs
Equipment IP Rang Protecon
System IPX0 Not protected
Paent support t
able base IPX1 Protected against vercally falling water drops
Paent support tabletop IPX2 Protected against vercally falling water drops
when enclosure lted up to 15 degrees
Viewpad IPX2 Protected against vercally falling water drops
when enclosure lted up to 15 degrees
Review module IPX2 Protected against vercally falling water drops
when enclosure lted up to 15 degrees
Pan handle IP03 Protected against spraying water
Control module IPX4 Protected against splashing water
Touch screen module IP44 Protected against splashing water
Foot switch (wired and wireless) IPX8 Protected against the eects of connuous immer-
sion in water
16.2 X-ray System Con
guraon
The following table gives an overview of the X-ray tube usage for each system:
Monoplane Systems Catalog Number X-ray Tube
Azurion 3 M12 722 063 MRC 200+ 0508 ROT-GS 1003
Azurion 3 M15 722 064 MRC 200+ 0407 ROT-GS 1004
