Monoplane Systems Catalog Number X-ray Tube
Azurion 7 M12 722 078 MRC 200+ 0508 ROT-GS 1003
Azurion 7 M20 722 079 MRC 200+ 0407 ROT-GS 1004
Biplane Systems Catalog Number Frontal X-ray Tube Lateral X-ray Tube
Azurion 7 B12 722 067 MRC 200+ 0508 ROT-GS
1003
MRC 200+ 0508 ROT-GS
1003
Azurion 7 B20 722 068 MRC 200+ 0407 ROT-GS
1004
MRC 200+ 0508 ROT-GS
1003
MRC 200+ 0508 ROT-GS 1003 and cooling unit CU 3101
NOTE If your system has been upgraded, the X-ray tube may be MRC 200 0508 ROT-GS 1003. Any
di
erences in specicaon are indicated below.
Item Specicaon
Maximum voltage Fluoroscopy: 120 kV
Exposur
e: 125 kV
Maximum tube current Large focus: 1063 mA at 80 kV
Small focus: 563 mA at 80 kV
Tube current for pulsed uoroscopy with grid control 10 mA - 200 mA
Connuous loadability (at 23°C) 4000 W
(MRC 200: 3200 W)
• Maximus ROTALIX Ceramic tube MRC 200+ 0508 ROT-GS 1003 with anode heat storage capacity of
6.4 MHUe
 and 0.5/0.8 mm nominal focal spot values, maximal 45 and 85 kW short me load.
– MRC 200: Anode heat storage capacity of 2.4 MHU
• Grid switching at pulsed uoroscopy
• Tube housing ROT-GS 1003 for oil-cooled X-ray tube with thermal safety switch
• Cooling unit heat exchanger for direct and connuous forced cooling with oil
• Rotor control
• High-voltage cables
• Cover parts
MRC 200+ 0407 ROT-GS 1004 and cooling unit CU 3101
NOTE If your system has been upgraded, the X-ray tube may be MRC 200 0407 ROT-GS 1004. Any
dierences in specicaon are indicated below.
Item Specicaon
Maximum voltage Fluoroscopy: 120 kV
Exposur
e: 125 kV
Maximum tube current Large focus: 813 mA at 80 kV
Small focus: 353 mA at 85 kV
Tube current for pulsed uoroscopy with grid control 10 mA - 160 mA
Connuous loadability (at 23°C) 4000 W
(MRC 200: 3200 W)
• Maximus ROTALIX Ceramic tube MRC 200+ 0407 ROT-GS 1004 with anode heat storage capacity of
6.4 MHUe
 and 0.4/0.7 nominal focal spot values, maximal 30 and 65 kW short me load
– MRC 200: Anode heat storage capacity of 2.4 MHU
• Grid switching at pulsed uoroscopy
• Tube housing ROT-GS 1004 for oil-cooled X-ray tube with thermal safety switch
• Cooling unit heat exchanger for direct and connuous forced cooling with oil
• Rotor control
Technical Informaon X-ray System Conguraon
Azurion Release 1.2 Ins
trucons for Use 269 Philips Healthcare 4522 203 52421
